Sensors & Encoders
VEGA Laser Power and Energy Meter P/N Industrial Sensor Encoder Measurement
P/N 7Z01560
$5,500.00
In Stock
🔍 Hover to zoomRobust heavy-duty incremental encoder engineered for reliable performance in demanding industrial environments
| Brand | Baumer |
| Model | HOG10DN1024ISR16H7KLK |
| Voltage | 10-30V DC |
| Country of Origin | Switzerland |
| Weight | 2.5 kg |
| Dimensions | Ø100 x 75 mm |
| Warranty | 24 months |
| Certifications | CE, UL, RoHS, IEC 61010 |
| SKU / MPN | HOG10DN1024ISR16H7KLK |
| What’s in the box | Encoder unit, mounting kit, installation manual |
| Resolution | 1024 PPR |
| Output Type | Push-pull (HTL/TTL) |
| Shaft Type | Hollow shaft Ø16mm H7 keyway |
| Protection Class | IP67 |
| Operating Temperature | -40°C to +100°C |
| Connection | Radial M16 connector |
Key benefits: High resolution 1024 PPR, rugged IP67 housing, wide temperature range, hollow shaft design with keyway, vibration-resistant construction, long service life
Typical applications: Steel mills, paper machines, cranes, wind turbines, heavy machinery, marine propulsion systems, mining equipment
Lifecycle: Active product, long-term availability with 10+ years support
